0.6 / 1kV Steel Wire Armoured Electrical Cable 2 Years Warranty VV32 4x240mm2

0.6 / 1kV Steel Wire Armoured Electrical Cable 2 Years Warranty VV32 4x240mm2

MOQ: 500 МЕТРОВ
цена: US$0.35~112 per Meter
Стандартная упаковка: ударные
Срок доставки: 10 ДНЕЙ
Способ оплаты: T / T, L / C
Пропускная способность: 10.000 KM/месяц
Подробная информация
Место происхождения
Китай
Фирменное наименование
QINGDAO YICABLE CABLE
Сертификация
ISO,CE,IEC,TUV,KEMA
Тип кабеля:
Кабель SWA
Номинальное напряжение:
0.6/1kV
Изоляция:
ПВХ
проводник:
Медь
панцырь:
оцинкованной стальной проволоки
Размеры:
1mm2 | 630mm2
Стандарты:
IEC/BS//VDE
Гарантия:
2-х лет
Выделить:

armored electrical wire

,

armoured power cable

Описание продукта

0.6 / 1kV Steel Wire Armoured Electrical Cable 2 Years Warranty VV32 4x240mm2



Applications



Apply to shafts,water and soil,able to bear the larger positive pressure.
Used for power transmission and distribution line with voltage rated at 1.1kV and below.





Cable details



1. U0/U: 0.6/1kV



2. Standard: IEC60502, BS7870, GB/T12706



3. Max. working temperature: 90 °C , can be 110 °C as requirement



4. Conductor: Class 1/2 annealed bare copper/aluminum solid or strands



5. Insulation: XLPE/PVC



6. Armored: STA



7. Sheath: PVC



8. Cross section area: 1.5~630mm2



9. Cores: 1~5 cores,3C+1E,4C+1E,3C+2E



10. Packing:Wooden drum or as requirement



11.Certification : ISO9001/ISO14001/OHSAS18001/CCC/CE/CB



12.Remark: Flame retardant,fire resistance,low smoking and Halogen free,or other property can be avaliable





YJ: XLPE insulation

V: PVC insulation

V: PVC sheath

22: Galvanized steel tape armoring

32: Galvanized steel wire armoring






Standards:



IEC 60502, 60228, 60332, 60331

DIN VDE 0276-620
HD 620 S1: 1996
DIN EN 60228 class 2 (construction)




Technical data:


Test voltage 0.6/1 kV [kV] 3.5 / 5 min.
Temperature range in motion -5°C till +70°C
fixed -20°C till +70°C
Operating temperature short circuit °C 250
Short circuit time max. [sec] 5
Bending radius min. x diameter 15
Flammability standard EN 60332-1-2





Type Desciption Rated Voltage NO. of Cores Nomibal section(mm2) Applications
YJV YJLV Cu or Al conductor,XLPE insulated.PVC sheathed electric cable 0.6/1KV 1,2,3,4 1.5 to 400 For laying indoors and outdoors.The LV XLPE insulated power cable is used in transmission and distribution system at rated voltagae U(Um) ≤10KV.The HV XLPE insulated power cable refers to the power cable transmission between 10KV-35KV, it is often applied to the main road of power transmission. Able to bear certain traction during installation, but not external mechanical forces.
3+1 3×4+1×2.5 to 3×400+1×185
6/6kV 1,3 25 to 500
8.7/10kV 8.7/15kV 12/20kV 1 25 to 500
3 25 to 300
21/35kv 1 50 to 500
YJV22 YJLV22 Cu or Al conductor,XLPE insulated steel tape armoured PVC sheathed electric cable 0.6/1KV 3 1.5 to 400 Suitable for burying in ground, Able to bear external mechanical forces but large pulling forces.
4 4 to 240
6/6kV 8.7/10kV 8.7/15kV 12/20kV 3 25 to 300
21/35kv 3 50 to 240







Packing & Shipping


We are capable of meeting the most strict delivery schedules according to per purchase order. Meeting the deadline is always the top priority as any delay in the delivery of cable can contribute to overall project delay and cost overrun.



Cable is supplied in wooden reels, corrugated boxes and coils. Cable ends are sealed with BOPP self adhesive tape and non-hygroscopic sealing caps to protect the cable ends from moisture. The required marking shall be printed with a weather-proof material on the outsides of drum according to customer's requirement.






Our Services


♦ We are the one of biggest manufacture of electric wire and power cable in China and has more than 20 years producing and marketing experience.
♦ We accept OEM. The cable size and material are customized.Ur own logo and own design are welcome. We will produce according to your requirement and description;
♦ Please send us inquiry for more products info and we will give you feedback in 12 hours.





FAQ

1. Shipping: By sea or air due to heavy weight. Samples will be send by DHL, Fedex. etc
2. Payment: We accept T/T, L/C , just choose what you like
3. Delivery time: Generally 7~10 working days upon receipt deposit. According to the quantity.
4. MOQ: Generally our MOQ is 1000meters. samples below 20 centimeter can be provided freely.


0.6 / 1kV Steel Wire Armoured Electrical Cable 2 Years Warranty VV32 4x240mm2 0


AFTER-SERVICE COMMITMENT:


Shanghai Shenghua Cable (Group) possesses Shenghua tenet "Strive for the Best Enterprise, Produce the Best Product, Provide the Best Service, Establish the Best Brand", insists the policy of quality first, endeavors to achieve high quality and zero defect of goods. Therefore, every client could fully benefit from Shenghua Cable's superior quality and faultless service. Meanwhile, we observe Shenghua spirit of "Do Best, Mutually Win", wish to establish long-term and stable relationship with every client. Hereby, we guarantee that:

1. Customer is God. We will cherish every client, every cooperation by heart.
2. Free pre-sales service. We will provide best proposal for each client.
3. Good sales service. We will provide free relative product operation, maintenance tips and installation commissioning
technical advisory service when establish cooperation relationship with clients.
4. Thoughtful after sales service . Our product are warranted by PICC(People's Insurance Company of China). We will
provide free maintaining and debugging within 12 month after installation(except for the wrong using).
5. We guarantee solve your problems within 24 hours in Shanghai, 72 hours for other district.
6. 24 hours hot-line telephone service. We will appoint professional person answer your question timely.

We always firmly believe that " Quality is life line, Service is laissez-passer", which will make us more closer and tight!

Shanghai Shenghua Cable (Group) Co., Ltd.
